Custom WorkShop Pro 'plug-in' for Punch! v21 Pro

Custom Workshop Pro adds over 90 professional CAD tools to Punch! Home Design. Its diverse feature set, consisting of 2D drafting, 3D modeling, editing, and data sharing tools allows the user to create virtually any object to complement their home design project.
$99.99
Availability: In stock
SKU
45780

This new Punch! PowerTool adds over 90 professional CAD tools to Punch! Home Design. Its diverse feature set, consisting of 2D drafting, 3D modeling, editing, and data sharing tools allows the user to create virtually any object to complement their home design project. Objects created can be saved to your library and used with any of your home and landscape designs. Custom Workshop Pro can bring in popular CAD file formats such as SketchUp®, 3D Studio®, 3MF, STL, DAE, PLY, as well as Adobe® Illustrator®, PDF, SVG, TIFF, BMP, PNG, and JPG.

Some of the features included in Custom Workshop Pro:

2D Drafting Features:

  • Line Tools (8 methods)
  • Arc Tools (5 methods)
  • Circle Tools (7 methods)
  • Ellipse Tools (5 methods)
  • Polygon Tools (7 methods)
  • Bezier Spline Tool Fillet/Chamfer (5 methods)
  • Spline Fill

3D Modeling Features:

  • Primitives (6 types)
  • Extrude, Lathe, Skin, Cover
  • Booleans (Add, Subtract, Intersect)
  • Subdivision (Add Loop, Fill, Bridge, Inset)
  • Split & Slice

Modification and Editing:

  • Align, Group, Ungroup, Copy, Paste
  • Transformations (Translate, rotate, scale, mirror, along the path)
  • Arrays (Polar and Rectangular)
  • Magnet Tool

Data Sharing:

DWG/DXF, SketchUp®, 3D Studio®, 3MF, STL, DAE, Ply Adobe® Illustrator®, PDF, SVG, TIFF, BMP, PNG, JPG
